A Wideband SIW Cavity Structure Transverse Slot Antenna for 5G communications
Research Article | Published: 27 July 2025
ICCK Journal of Microwave and Antenna Engineering Volume 1, Issue 1, 2025: 1-7
Volume 1, Issue 1, ICCK Journal of Microwave and Antenna Engineering
Volume 1, Issue 1, 2025
Submit Manuscript Edit a Special Issue
Article QR Code
Article QR Code
Scan the QR code for reading
Popular articles
Research on A Ship Trajectory Classification Method Based on Deep Learning Case Studies on Integrating Artificial Intelligence in Finance to Transform Decision Making and Risk Management for Enhanced Financial Outcomes Bridging Modalities: A Survey of Cross-Modal Image-Text Retrieval A Mimic Fusion Algorithm for Dual Channel Video Based on Possibility Distribution Synthesis Theory YOLOv7-Bw: A Dense Small Object Efficient Detector Based on Remote Sensing Image Deep Prediction Network Based on Covariance Intersection Fusion for Sensor Data Visual Feature Extraction and Tracking Method Based on Corner Flow Detection Inaugural Editorial of the Chinese Journal of Information Fusion YOLOv8-Lite: A Lightweight Object Detection Model for Real-time Autonomous Driving Systems Enhancing Fake News Detection with a Hybrid NLP-Machine Learning Framework
ICCK Journal of Microwave and Antenna Engineering, Volume 1, Issue 1, 2025: 1-7

Open Access | Research Article | 27 July 2025
A Wideband SIW Cavity Structure Transverse Slot Antenna for 5G communications
by
Abhinav Mishra Abhinav Mishra 1,2 *
Azharuddin Khan Azharuddin Khan 3
Satya Kesh Dubey Satya Kesh Dubey 1,2
1 Academy of Scientific and Innovative Research (AcSIR), Ghaziabad 201002, India
2 CSIR–National Physical Laboratory (Electromagnetic Metrology Section), New Delhi 110012, India
3 Department of Electronics Engineering, Indian Institute of Technology (Banaras Hindu University), Varanasi 221005, India
* Corresponding Author: Abhinav Mishra, [email protected]
DOI: 10.62762/JMAE.2025.681181
Received: 06 May 2025, Accepted: 31 May 2025, Published: 27 July 2025
   PDF  (4.11 MB)
Article Metrics Cite This Article
Abstract
This paper presents the design of a wideband cavity-structure transverse slot antenna based on a substrate integrated waveguide (SIW) for fifth-generation (5G) applications. The antenna is specifically engineered to cover the European 5G frequency range (24.25 – 27.5 GHz). By strategically positioning multiple resonant slots on the bottom metal cladding of the SIW cavity, hybrid modes are generated within the desired frequency band. The characteristics of these modes can be adjusted by altering the slot parameters, resulting in the merging of wideband resonance frequencies. Simulation results demonstrate a bandwidth of 3.3 GHz (13.58%), spanning from 23.5 GHz to 26.8 GHz, with a gain of 10.34 dBi across the bandwidth and a cross-polarization level below -35 dB. The proposed antenna is compared to previously reported designs, evaluating its performance in terms of reflection coefficient, bandwidth, gain, optimized parameter values, and radiation pattern. The total volume of the proposed design, including the feedline, is 36.6 mm × 26.7 mm × 1.572 mm.
Graphical Abstract
A Wideband SIW Cavity Structure Transverse Slot Antenna for 5G communications
Keywords
transverse slot Antenna
EM-Field
5G applications
Data Availability Statement
Data will be made available on request.
Funding
This work was supported without any funding.
Conflicts of Interest
The authors declare no conflicts of interest.
